Feature The SF100 is a high speed 'In System Programming' programmer to update the SPI Flash soldered on board or Freescale MCU using Ezport. The programmer is easily controlled by the computer DediProg Software through the USB bus offering a friendly interface and powerful features to users.

High performance USB Mode Reference IC Density (Program + Verify) Memory size W25X80VSSIG 8Mb 11s W25Q16VSSIG 16Mb 15s W25Q32VSSIG 32Mb 20.5s W25Q64FVSSIG 64Mb 48.5s W25Q128BVFIG 128Mb 94s W25Q256FVFIG 256Mb 157s S25FL512SAGMFI011 512Mb 297s *Please note the programming and verify time will depend on different IC type; please refer to the IC specification before programming. Hardware SF100 is designed with ISP header, through an appropriate connector; users can connect the programmer and drive the SPI signals, supply the memory and control the controller or application status. Please refer to Table 1 for the SF100 2x7 header pin out. DediProg also provides the SF100 ISP Cable which is used to connect the SF100 programmer to the 2X4 2.54mm ISP Pin Header on board, please refer to Table 2 for the SF100 ISP Cable 2x4 pin out. Metex ms 9150 manual muscle oil. Table 1: SF100 ISP Header Pin Out (2x7) 1 I/O1 I/O4 2 3 I/O2 or CS2 NC 4 5 Vcc GND 6 7 CS CLK 8 9 MISO MOSI 10 11 Vpp/Acc I/O3 12 13 SCL SDA 14 Table 2: ISP Cable Connector Pin Out (2x4) 1 Vcc GND 2 3 CS CLK 4 5 MISO MOSI 6 7 Vpp/Acc I/O3 8 The SF100 USB software tool chain offers high flexibility and fits different and the highest requirements. Hardware Requirement for ISP: To have a clear understanding on the different ISP or backup boot methods and different reference schematics, please download our dedicated application notes: and Standard Package • SF100 Programmer x 1 • USB cable x 1 • ISP cable x 1 • SF100 Universal Adaptor x 1 • CD-ROM x 1(Included Software, specifications, and user manual) Optional Purchase • Backup Boot Flash Module-8N • Backup Boot Flash Module-8W • Backup Boot Flash Module-D8W • Backup Boot Flash Module-DIP • Backup Boot Flash Module-16W • Backup Boot Flash Module QUAD-8W Related Accessories. Product File Type File Description Version Download File size Last Update SF100 ISP IC Programmer Software DediProg software 6.0.5.20 New 9.01MB 2018-07-04 16:45:55 SF100 ISP IC Programmer Software Linux software for SF100, SF600 and SF600Plus Support Linux OS: Ubuntu, Fedora and Centos. Black angels kronos quartet rar software free download torrent.

Add --device command. 1.2.1.03 72.68KB 2017-09-28 15:31:57 SF100 ISP IC Programmer Software USB Driver - Update Digital Signature 5.23MB 2016-11-10 18:19:13 SF100 ISP IC Programmer Firmware SF100 V5 Firmware (for win8.1 and later) 5.5.03 28.25KB 2016-11-22 13:11:09 SF100 ISP IC Programmer Manual User manual for SF100 / SF600 / SF600Plus / SF700 Updated 1. Add SF700 information 2. Modify the picture of engineering mode in Ch.3.5.3. Modify picture of standalone start mode. 7.7 2.52MB 2019-01-02 15:28:02 SF100 ISP IC Programmer Manual USB Driver User Guide for Win 8 / 8.1 / 10 Applicable Model:EM100Pro / EM100Pro-G2 / SF100 / SF600 / SF600Plus / EE100 / StarProg Series / ProgMaster Series 1.0 645.00KB 2018-09-10 09:59:38 SF100 ISP IC Programmer Manual SF Series FAQ 1.1 742.92KB 2018-08-24 17:30:42 SF100 ISP IC Programmer Manual SF Firmware Support for Windows Update Procedure for SF series for SF100 / SF600 / SF600Plus *If you need the firmware for Windows8.1/ Windows10, please contact DediProg sales.
