Easycap Usb 20 Driver Dc60
Easycap usb 2 0 driver free download - VIA USB 2.0 Host Controller Driver, Realtek RTL8187B Wireless 802.11b/g 54Mbps USB 2.0 Network Adapter, Realtek USB 2.0 Card Reader, and many more programs. How to install Win7 Win 10 64bit drivers and how to resolve heat issues with the EasyCAP video capture device. EasyCAP DC60 sm-usb 007 - How To - Win7 Win10 64bit Drivers and Heat.
Some time ago Ezequiel Garcia informed me: 'I just wanted you to know I've re-worked the old easycap driver from scratch. Now it's called stk1160, because it's the correct name for such driver. ' Inbetween the driver has been succesfully tested on Ubuntu 12.04 and Bodhilinux 1.4.0 with kernel 3.2. So it should work even on most systems which have the 3.2.0 kernel. Although some enhancements have to be done, the driver already can be used as a replacement of the easycapdriver.
It is expexted that the driver soon will get into the mainline kernel. The great improvements compared to the easycapdriver are: - there is no framedropping anymore - the snd_usb_audio issue is solved - the driver loads and registers quicker than the easycapdriver Installation and usage (tested on Ubuntu 12.04). Modinfo stk1160 After plugging in the EasyCAP test it with mplayer: mplayer tv:// Configure sound The stk1160 module registers a control-only alsa soundcard. This sound card is called 'stk1160-mixer'.
The real sound capture is done through the 'Controlle' soundcard which is also created after plugging in the EasyCAP. To get a list of the registerd ALSA soundcards, run the following command: cat /proc/asound/cards Sample output: 0 [Intel ]: HDA-Intel - HDA Intel HDA Intel at 0xf0580000 irq 43 1 [Controlle ]: USB-Audio - USB 2.0 Video Capture Controlle Syntek Semiconductor USB 2.0 Video Capture Controlle at usb-0000:00:1d.7-2, hig 2 [stk1160mixer ]: stk1160 - stk1160-mixer stk1160 ac97 codec mixer control To enable sound capture you have to open alsamixer when the EasyCAP is plugged in and select the 'Line' item on the capture menu for stk1160-mixer device: 1. Start alsamixer 2.
Select stk1160-mixer sound card (with F6) 3. Select capture controls (with F4). In the viewing- or capturing program you must then select the 'Controlle' soundcard or its number to hear sound!
Reinstallation oft the driver is required after kernel update! If you have installed a new kernel on your system (or your update-manager did so automatically) you need to reinstall the stk1160 driver! When you do not want to use the stk1160 driver anymore Simply blacklist the stk1160 module as described above and revert the blacklisting of the easycap module. Thanks to Ezequiel for his work and support! Possible that recent ubuntu upgrade broke the audio.
Stk1160mixer is not being created. I had the audio working like week ago in one computer and now it does not work anymore. Tested in 2 different machines with ubuntu 12.04 dmesg tells me [ 385.584324] usb 2-2: new high-speed USB device number 4 using ehci_hcd [ 385.717477] usb 2-2: New device Syntek Semiconductor USB 2.0 Video Capture Controller @ 480 Mbps (05e1:0408, interface 0, class 0) [ 385.717487] usb 2-2: video interface 0 found [ 386.044729] saa71: saa7113 found (1f7113d0e100000) @ 0x4a (stk1160) [ 386.764433] stk1160: driver ver 0.9.3 successfully loaded [ 386.797463] stk1160: registers to NTSC like standard [ 386.801497] AC'97 0 access is not valid [0x0], removing mixer. [ 386.968669] stk1160 2-2:1.0: V4L2 device registered as video0 [ 386.990731] usbcore: registered new interface driver snd-usb-audio When I execute amixer -c stk1160mixer sset Line unmute cap I get $ amixer -c stk1160mixer sset Line unmute cap Invalid card number.
Usage: amixer [command] Available options: -h,--help this help. Hi, I cannot reproduce your problem. I'm also using Ubuntu 12.04 with the latest updates (kernel 3.2.0-30-generic-pae at present). The stk1160 driver works as before on my machine.
